WL-433 – LoRa 433MHz Gateway Powerful Long-Range Control
WL-433 – LoRa 433MHz Gateway
Powerful Long-Range Control for Smart Lighting Integration
Unlock ultra-long-range wireless lighting control with the WL-433 – a robust LoRa 433MHz gateway designed for seamless connectivity across Mi-Light and MiBoxer LoRa series products. With support for smartphone app control, third-party voice assistants, and DMX512 to 2.4GHz signal conversion, this gateway is the bridge between advanced smart lighting protocols and user convenience.
Whether managing expansive outdoor installations or complex DMX-controlled systems, the WL-433 delivers unmatched transmission reach and integration versatility.
💡 Key Features
✅ LoRa 433MHz Protocol – Ultra-long-distance transmission up to 1000m in open areas
✅ DMX512 to 2.4GHz Bridge – Expand compatibility with MiBoxer 2.4GHz systems
✅ Smartphone & Voice Control – Use via app or integrate with Alexa/Google Assistant
✅ Industrial Strength Range – Penetrates up to 50m through freshwater or dense environments
✅ WiFi 2.4GHz Connectivity – Easy network pairing with standard smart home setups
📊 Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | WL-433 |
| Input | DC 5V/500mA (5.5×2.1mm) |
| RF Protocol | 433MHz LoRa Spread Spectrum |
| Transmitting Power | 15dBm |
| Control Distance | 50m (0.5m submerged), 1000m (open area) |
| Communication | WiFi IEEE 802.11 b/g/n (2.4GHz) |
| DMX Support | DMX512 (1990 Standard) |
| Working Temp | -20℃ to 60℃ |
🛡️ Warranty
2-Year Manufacturer Warranty
Original: $46.50
-70%$46.50
$13.95
Description
WL-433 – LoRa 433MHz Gateway
Powerful Long-Range Control for Smart Lighting Integration
Unlock ultra-long-range wireless lighting control with the WL-433 – a robust LoRa 433MHz gateway designed for seamless connectivity across Mi-Light and MiBoxer LoRa series products. With support for smartphone app control, third-party voice assistants, and DMX512 to 2.4GHz signal conversion, this gateway is the bridge between advanced smart lighting protocols and user convenience.
Whether managing expansive outdoor installations or complex DMX-controlled systems, the WL-433 delivers unmatched transmission reach and integration versatility.
💡 Key Features
✅ LoRa 433MHz Protocol – Ultra-long-distance transmission up to 1000m in open areas
✅ DMX512 to 2.4GHz Bridge – Expand compatibility with MiBoxer 2.4GHz systems
✅ Smartphone & Voice Control – Use via app or integrate with Alexa/Google Assistant
✅ Industrial Strength Range – Penetrates up to 50m through freshwater or dense environments
✅ WiFi 2.4GHz Connectivity – Easy network pairing with standard smart home setups
📊 Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | WL-433 |
| Input | DC 5V/500mA (5.5×2.1mm) |
| RF Protocol | 433MHz LoRa Spread Spectrum |
| Transmitting Power | 15dBm |
| Control Distance | 50m (0.5m submerged), 1000m (open area) |
| Communication | WiFi IEEE 802.11 b/g/n (2.4GHz) |
| DMX Support | DMX512 (1990 Standard) |
| Working Temp | -20℃ to 60℃ |
